Drainage Archives

Link	Country	Year	Total Length [m]	Nominal Diameter DN [mm]	Nominal Pressure PN [bar]	Nominal Stiffness SN [N/m²]	Technology
Warszawa, Narwik & Pelczynskiego Streets – storm sewer	Poland	2003	666	250 \| 800	1	10000	Hobas
Warszawa, Daimler-Chrysler – storm sewer	Poland	2003	84	300	1	10000	Hobas
Turek, Zdrojki Lewe – storm sewer	Poland	2003	2126	500 \| 1200	1	5000	Hobas
Tomaszow Mazowiecki, culvert under railway	Poland	2003	54	500	1	5000	Hobas
Szczecin, Bronowicka Street – storm sewer	Poland	2003	1842	500 \| 600	1	10000	Hobas
Poznan, Airport Krzesiny – storm sewer	Poland	2003	222	200 \| 400	1	10000	Hobas
Lask, Airport – drainage	Poland	2003	252	200 \| 250	1	10000	Hobas
Kwidzyn, stormwater sewer	Poland	2003	54	600	1	2500	Hobas
Krakow, Airport Balice – storm sewer	Poland	2003	1332	200 \| 1600	1	10000	Hobas
Kedzierzyn, Jana Pawla II Street – storm sewer	Poland	2003	426	200 \| 500	1	10000	Hobas
Grubno near Chelmno, culvert under road	Poland	2003	13	600	1	5000	Hobas
Gdansk Wrzeszcz, GCH Manhattan – storm sewer	Poland	2003	775	300 \| 1400	1	10000 \| 5000	Hobas
Czestochowa, Culvert – DK1	Poland	2003	18	300	1	10000	Hobas
Bialystok – storm sewer at Bazantarka river	Poland	2003	2332	300 \| 1600	1	10000	Hobas
Gyor, Audi Hungaria Motor Kft.	Hungary	2003	102	150 \| 400	1	2500 \| 10000	Hobas
Mecseknadasd	Hungary	2003	324	400	1	5000	Hobas
Mecseknadasd	Hungary	2003	63	1000	1	2500 \| 10000	Hobas
Papa, TESCO	Hungary	2003	324	400	1	5000	Hobas
Bridge, street and highway drainage Ebensfeld-Erfurt (Wümbachtalbrücke)	Germany	2003	600	200 \| 250	1	5000	Hobas
Bridge, street and highway drainage Dresden (Walterstraße)	Germany	2003	1015	150 \| 200	1	5000	Hobas
Bridge, street and highway drainage Ebensfeld-Erfurt (Röstalbrücke)	Germany	2003	139	200	1	5000	Hobas
Bridge, street and highway drainage Hirschbach (Leuketalbrücke)	Germany	2003	159	150 \| 200	1	5000	Hobas
Bridge, street and highway drainage Regensburg (Donaubrücke Pfaffenstein)	Germany	2003	1364	150 \| 200 \| 250 \| 300	1	5000	Hobas
Zagreb, Buzin	Croatia	2002	1780	200 \| 400 \| 600 \| 800	1 \| 1 \| 6 \| 1	10000 \| 10000 \| 10000 \| 10000	Hobas
Rijeka, Kostrena	Croatia	2002	1086	1200 \| 1400	1 \| 1	5000 \| 5000	Hobas
Wroclaw, Gadowska overpass	Poland	2002	1002	150 \| 250	1	10000	Hobas
Warszawa, Trasa Siekierkowska – Nowa Ulga	Poland	2002	503	300 \| 1000	1	10000	Hobas
Warszawa, Siekierkowski Bridge on the Wisla river	Poland	2002	1425	300 \| 400	1	10000	Hobas
Lublin, Poniatowskiego Viaduct	Poland	2002	8	150	1	10000	Hobas
Bydgoszcz, Bridge on the Brda river	Poland	2002	150	200 \| 300	1	10000	Hobas
