Drainage Archives

Link	Country	Year	Total Length [m]	Nominal Diameter DN [mm]	Nominal Pressure PN [bar]	Nominal Stiffness SN [N/m²]	Technology
Bridge, street and highway drainage Weidengraben Brücke (Bundesautobahn A 38)	Germany	2004	626	200 \| 250	1	5000	Hobas
Bridge, street and highway drainage Taubentalsbach Brücke (Bundesautobahn A 38)	Germany	2004	515	150 \| 200 \| 250 \| 300	1	5000	Hobas
Bridge, street and highway drainage Bundesautobahn A 113	Germany	2004	217	200	1	5000	Hobas
Bridge, street and highway drainage Bundesautobahn A 113	Germany	2004	180	200 \| 400	1	5000 \| 10000	Hobas
Bridge, street and highway drainage Wustermarkt (Bundesautobahn A 10)	Germany	2004	144	150 \| 200	1	5000	Hobas
Varaždin	Croatia	2003	1035	2400	1	10000	Hobas
Adria Highway, bridges from Mala Kapela to Gornja Ploča	Croatia	2003	10278	300 \| 400 \| 500	1 \| 1 \| 1	2500 \| 2500 \| 2500	Hobas
Krapina – Bobovje	Croatia	2003	1800	600 \| 700	1	5000 \| 5000	Hobas
Zelazna, Bridge on Biala Ladecka river drainage	Poland	2003	186	200	1	10000	Hobas
Wielewo, Bridge on Pasleka river drainage	Poland	2003	150	300	1	10000	Hobas
A4 Wedroze Wielkie – Bielany Wroclawskie, Viaduct drainage, K11-K13	Poland	2003	382	200	1	10000	Hobas
Szczecin, Bridge M3 on Regalica river drainage	Poland	2003	531	200 \| 300	1	10000	Hobas
Srarogard Gdanski, Bridge on Wierzyca river drainage	Poland	2003	48	200	1	10000	Hobas
DK 42 Skarzysko Kamienna, Legionow Street – Viaduct drainage	Poland	2003	192	200	1	10000	Hobas
Wolin – Bridge over Dziwna river – ring road	Poland	2003	1836	150 \| 300	1	10000	Hobas
Plock Radziwie, bridge on Wisla river drainage	Poland	2003	3	600	1	5000	Hobas
Nowy Targ, bridge on Mlynowka river drainage	Poland	2003	142	300	1	10000	Hobas
Kiezmark, bridge on Warta river drainage	Poland	2003	1927	150 \| 400	1	10000 \| 5000	Hobas
DK 717 Jelowka, Pisia river – bridge river	Poland	2003	22	200	1	10000	Hobas
Dzialoszyn, bridge over the Warta river drainage	Poland	2003	216	200	1	10000	Hobas
Zyrardow, Jaktorowska Street – storm sewer (jacking under railway, road)	Poland	2003	90	550 \| 750	1	320000	Hobas
Slawkow, South Slawkow Bridge – culvert of rail	Poland	2003	33	900	1	32000	Hobas
DK-6 Pobiedziska, embankment of rail – sanitary sewer	Poland	2003	122	250	1	640000 \| 320000	Hobas
Ostroleka, Traugutta Street – storm sewer	Poland	2003	24	1000	1	32000	Hobas
Mienia – culvert of rail	Poland	2003	94	1300	1	100000	Hobas
Kielce Bialogon, Zalesie Street – culvert under railway	Poland	2003	36	300	1	100000	Hobas
Ciechanow, os. Zachod – storm sewer	Poland	2003	24	600	1	200000	Hobas
Wrzesnia, culvert under A2	Poland	2003	96	1200	1	5000	Hobas
Witaszyczki, culvert and road	Poland	2003	12	700	1	10000	Hobas
Warszawa, Zlota Street, Zlote Tarasy – combined sewer	Poland	2003	300	1000	1	10000	Hobas
